DigitalMedia 8G+™ Receiver 200 Crestron DM-RMC-200-C
DM-RMC-200-C Specifications (Continued)
SPECIFICATION DETAILS
Audio (Continued)
Performance (Analog)
Amplifier Output Power
8
15 Watts per channel at 8 Ohms
Frequency Response
20 Hz to 20 kHz ±0.5 dB (line),
20 Hz to 16 kHz ±3 dB (speaker)
S/N Ratio
>95 dB (line), >75 dB (speaker)
20 Hz to 20 kHz A-weighted
THD+N
<0.005% @ 1 kHz (line),
<0.3% @ 1 kHz (speaker)
Stereo Separation >90 dB (line), >60 dB (speaker)
Volume Gain Range (Analog) -80 dB to 0 dB
Communications
DigitalMedia
DM 8G+, HDCP management, EDID
format management, CEC
Ethernet
10BASE-T/100BASE-TX, auto-switching,
auto-negotiating, auto-discovery,
full/half duplex, TCP/IP, UDP/IP,
CIP, DHCP, RSTP
USB Supports USB HID class devices
Power Requirements
Power Pack
2 Amps @ 24 Volts DC;
100-240 Volts AC, 50/60 Hz power pack
included
Minimum 2-Series Control System
Update File
9, 10
Version 4.003.0015 or later
Environmental
Temperature 32º to 104º F (0º to 40º C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation
Power amp off: 50 BTU/Hr;
Power amp on: 60 BTU/Hr (typical),
165 BTU/Hr (maximum)
Enclosure
Chassis Metal, black finish, vented sides and front
Mounting
Mounts to a 2-gang electrical box,
2-gang UK (BS 4662) electrical box,
or 2-gang European (DIN 49073)
electrical box;
Bracket includes holder for the included
power pack
Dimensions
Height 7.92 in (202 mm)
Width 10.84 in (276 mm) including bracket
Depth 1.85 in (47 mm) including bracket
Weight
3.3 lb (1.5 kg) including bracket and
power pack
Included Accessory Universal 24 Volt DC Power Pack
(Continued on following page)
8 • DigitalMedia 8G+™ Receiver 200: DM-RMC-200-C Operations & Installation Guide – DOC. 7126B
