5. The DM OUT port consists of one RJ-45 connector. Refer to the following table for the
connector pinouts.
DM OUT Connector Pinouts
18
PIN # WIRE COLOR PIN # WIRE COLOR
1 Orange/White 5 Blue/White
2 Orange 6 Green
3 Green/White 7 Brown/White
4 Blue 8 Brown
6. Power over DM requires connection to a DM 8G+ power sourcing device.
7. For DM 8G+ wiring up to 330 feet (100 meters) between devices, use Crestron DM-CBL-8G
DigitalMedia 8G cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D
cable, or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to
safeguard against unpredictable environmental electrical noise which may impact performance at
resolutions above 1080p. Refer to the latest version of the Crestron DigitalMedia Infrastructure Guide
(Doc. 4556) for complete wiring guidelines and to the Crestron DigitalMedia Design Guide (Doc.
4789) for complete system design guidelines. All cable sold separately.
Operations & Installation Guide – DOC. 6958B DigitalMedia 8G+™ Transmitter 201: DM-TX-201-C • 13

Crestron DM-TX-201-C Specifications

General

Type	Network transmitter
Duplex system	Full, Half
Auto-negotiation	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3at
RJ-45 ports quantity (transmitter)	2
Product color	Black
Output current	0.75 A
Output voltage	24 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	32 mm
Width	187 mm
Height	165 mm
Weight	721 g
