Crestron DM-TX-201-C User Manual

Crestron DM-TX-201-C DigitalMedia 8G+™ Transmitter 201
DigitalMedia 8G+™ Transmitter 201:
DM-TX-201-C
DigitalMedia 8G+™ Transmitter 201:
DM-TX-201-C
Introduction Introduction
The DM-TX-201-C provides a simple interface solution for computers and other
high-resolution AV sources as part of a complete DigitalMedia™ system. With both
HDMI
®
and RGB inputs, the DM-TX-201-C is ideal for use at a lectern, conference
table, wall plate, or any remote location in a boardroom, classroom, or residence to
provide an input for a laptop computer, DVD player, or similar source. It connects to
the head end or display location using a single CAT5e or Crestron
®
DM 8G™ cable.
Features and Functions
• DigitalMedia 8G+™ transmitter and multimedia interface
• Built-in 2x1 AV switcher
• DM 8G+™ output supports up to 330 feet (100 meters) cable length
1
• Low-profile surface-mount design
• Provides HDMI and RGB/component video inputs
• Supports DVI and DisplayPort Multimode sources
2
• Includes mini-TRS stereo audio input
• Provides onboard auto-switching capability
• Includes a local HDMI monitor output
• Includes USB HID (Human Interface Device) port for connection to
a computer
• Provides a 10BASE-T/100BASE-TX Ethernet connection
• Can be powered via DM or a local power pack
3
• Affords a true one-wire connection to a DM
®
switcher or receiver
(both sold separately)
• Detects and reports detailed video and audio input information
(Continued on following page)
1. For DM 8G+ wiring up to 330 feet (100 meters) between devices, use Crestron DM-CBL-8G
DigitalMedia 8G cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D
cable, or generic CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to
safeguard against unpredictable environmental electrical noise which may impact performance at
resolutions above 1080p. Refer to the latest version of the Crestron DigitalMedia Infrastructure Guide
(Doc. 4556) for complete wiring guidelines and to the Crestron DigitalMedia Design Guide (Doc.
4789) for complete system design guidelines. The manuals are available from the Crestron Web site at
www.crestron.com/dmresources. All cable sold separately.
2. HDMI requires an appropriate adapter or interface cable to accommodate a DVI or DisplayPort
Multimode signal. CBL-HD-DVI interface cable sold separately.
3. Power over DM requires connection to a DM 8G+ power sourcing device.
Operations & Installation Guide – DOC. 6958B DigitalMedia 8G+™ Transmitter 201: DM-TX-201-C • 1

Crestron DM-TX-201-C Specifications

General

Type	Network transmitter
Duplex system	Full, Half
Auto-negotiation	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3at
RJ-45 ports quantity (transmitter)	2
Product color	Black
Output current	0.75 A
Output voltage	24 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	32 mm
Width	187 mm
Height	165 mm
Weight	721 g
