Crestron IV-CAMFL-N-W-1B User Manual

Product Manual — Doc. 9321A IV-CAMFL-N-W-1B • 35
Command Set Command Command Packet Comments
Pan‐tiltDrive Up 8x 01 06 01 VV WW 03 01
FF
VV: Pan speed 0 x01 (low
speed) to 0 x18
(high speed)
Down 8x 01 06 01 VV WW 03 02
FF
Left 8x 01 06 01 VV WW 01 03
FF
Right 8x01 06 01 VV WW 02 03
FF
WW: Tilt Speed 0 x 01 (low
speed) to 0 x14
(high speed)
UpLeft 8x 01 06 01 VV WW 01 01
FF
UpRight 8x 01 06 01 VV WW 02 01
FF
DownLeft 8x 01 06 01 VV WW 01 02
FF
YYYY: Pan Position
DownRight 8x 01 06 01 VV WW 02 02
FF
Stop 8x 01 06 01 VV WW 03 03
FF
ZZZZ: Tilt Position
AbsolutePosition 8x 01 06 02 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z
FF
RelativePosition 8x 01 06 03 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z
FF
Home 8x 01 06 04 FF
Reset 8x 01 06 05 FF
Pan‐tiltLimitSet LimitSet 8x 01 06 07 00 0W
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z
FF
W: 1 UpRight 0: DownLeft
YYYY: Pan Limit Position
ZZZZ: Tilt Position
Inquiry Commands
Inquiry Command
Command
Packet
Inquiry Packet Comments
CAM_PowerInq 8x 09 04 00
FF
y0 50 02 FF On
y0 50 03 FF Off (Standby)
y0 50 04 FF Internalpower circuit error
