138 • TSW-70 Series ProductManual — Doc. 8550E
Configuration
Prior to configuration, ensure the device is running the latest firmware. To update the firmware,
refer to Update Firmware (on page177).
When power is applied for the first time, the following screen is displayed. The touch screen may
take up to two minutes to boot.
NOTE:TSW-70Rseries touch screens boot to the Crestron Home application setup screen. For
more information on configuring the Crestron Home application, refer to the Crestron Home
OS™ Product Manual.
Touch the screen to display the main Setup screen (TSW-1070 shown)
