Crestron TSW-770 User Manual

Dimension Drawings 94
Installation 95
TSW-570, TSW-770, and TSW-1070 Installation 96
Install the Mounting Bracket 96
Install the Security Bracket (Optional) 100
Connect the Touch Screen 101
Mount the Touch Screen 102
Configure the Touch Screen 103
Select an Application 105
TSW-570P Installation 107
Install the Mounting Bracket 107
Install the Security Bracket (Optional) 109
Connect the Touch Screen 110
Mount the Touch Screen 110
Configure the Touch Screen 111
Select an Application 114
TSW-770-GV and TSW-1070-GV Installation 116
Install the Mounting Bracket 116
Install the Security Bracket (Optional) 118
Connect the Touch Screen 119
Mount the Touch Screen 120
Configure the Touch Screen 121
Select an Application 123
TSW-570PR Installation 124
Install the Mounting Bracket 124
Install the Security Bracket (Optional) 126
Connect the Touch Screen 127
Mount the Touch Screen 127
Configure the Touch Screen 128
Configure the Crestron Home App 130
TSW-770R and TSW-1070R Installation 131
Install the Mounting Bracket 131
Install the Security Bracket (Optional) 133
Connect the Touch Screen 134
Mount the Touch Screen 135
Configure the Touch Screen 136
Configure the Crestron Home App 137
Configuration 138
Local Configuration 140
Access the Setup Screens 140
Ethernet Setup 142
IP Table Setup 145
iv • Contents ProductManual—Doc.8550E

Crestron TSW-770 Specifications

General

Display Size	7 in. (178 mm) diagonal
Touch Technology	Capacitive
Operating Temperature	32° to 104° F (0° to 40° C)
Contrast	800:1
Backlight	LED
RAM	2 GB
Power	PoE (802.3af)
Network	10/100 Mbps Ethernet
Audio	Speakers, Microphone
Mounting	Surface
Brightness	350 cd/m²
Ethernet	10/100 Mbps
Wi-Fi	802.11a/b/g/n/ac
Bluetooth	Bluetooth 4.2
Speakers	Yes
Video	H.264
Processor	Quad Core
Resolution	1280 x 800 pixels
