Product Manual — Doc. 8550E TSW-70 Series • 83

Power

PoE(Powerover

Ethernet)

IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device);

Normally requests 15 W from an 802.3at Type 2 PSE with LLDP advanced

power management;

With room scheduling and USB enabled, requests 18 W from an 802.3at Type 2

PSE with LLDP;

Requests 30 W (PoE+Class4) from an 802.3at Type 2 PSE without LLDP;

Requests 15.4 W (PoEClass0) from an 802.3af (or 802.3at Type 1)PSE

NOTE: Enabling the USB port requires use of an 802.3at Type 2 PoE+ PSE.

Environmental

Temperature 32 to 104 °F (0 to 40 °C)

Humidity 10% to 95% RH (noncondensing)

Heat Dissipation 44 BTU/hr

Construction

Housing Plastic, smooth black or white finish, edge-to-edge glass with black or white

surround

Mounting Surface mount over a 2 or 3-gang US electrical box, 2-gang European (DIN

49073) electrical box, or 2-gang UK (BS 4662) electrical box;

Lectern mount over a 2in. H x 3-3/4in. W (51mmHx 96mmW)cutout;

1-3/8in.(35mm) minimum mounting depth;

Wall mount, surface mount, and rack options available separately

Dimensions

Height 5.87 in. (149 mm)

Width 9.46 in. (240 mm)

Depth 2.01in. (51 mm)

Dimensions do not include mounting bracket or add-on accessories

Weight

1.61 lb (730 g)
