Removal and Replacement of ProStock Drawers Installation of Locker Drawer
8. Unplug diodes from wiring harness and then plug the connectors that were previously connected to
the each end of the diodes together (see Figures 11 and 12).
Figure 11, Connectors Showing One (1) Diode Removed
Figure 12, Connectors Connected without Diodes
9. Replace ProStock side cover.
Connectors Connected
Connectors with
Diode
13 of 13
