CribMaster ProStock - Figure 3, Screw Locations on Drawer Guides; Figure 4, Removal of Carousel Drawer

Removal of Carousel Drawer Removal and Replacement of ProStock Drawers
Figure 3, Screw Locations on Drawer Guides
7. With one person on each side, carefully lift the front part of the drawer up at an angle removing tabs
on the sides of the drawer from the slots on the drawer guides (see Figure 4).
Figure 4, Removal of Carousel Drawer
Drawer Tabs 4PL; (2 Right Side
Shown) (2 Left Side Not Shown)
Drawer Attachment Screw Locations (Both Carousel
and Locker; (4 PL); 2 Left Side (Shown); 2 Right Side
(Not Shown)
8 of 13
