14. Main circuit chart (Refer to drawing 2)
15. Complete Set Specification Table（ 5）
ytitnauQ noitpircseD metI
tes1 rotareneg gnidlew enilosag 091 BUC 1
cp1 launaM 2
cp1 launam enignE 3
16. Transport & Storage
The machines should be free from rain and snow during transportation and storage. The
warehouse should keep dry & ventilation and free from corrosive gas or dust. The tolerable temperature
ranges from ﹣25 (with no cooling water) ～﹢55℃ and the relative humidity can not be more than
85％.
17、 Quality Guarantee
Users are advised to operate in compliance with the stipulations given in the manual. On condition
that the welder is installed, stored, used, maintained, kept properly in compliance with the guideline, we
guarantee to get the welder repaired at our expense within 12 months upon the purchase of welder if and
when the welder is found either damaged partially or working improperly.
Explosive view（ 2）
