Crossfire XS-8K - POWER CONNECTIONS; +12 V Power; GROUND; REMOTE

GROUND
+12V Power
Connect the +12V terminal of the amplier to the positive (+) terminal of the battery using the same diameter
cable as the ground cable, making sure you install a in-line fuse holder, approximately 300 or 400 mm.
from the positive (+) terminal of battery.
GROUND
Disconnect the battery and connect the GND (ground) terminal to the cars chassis.
Keep this cable as short as possible (not longer than 20 inches or less).
Making sure that the connection with the chassis is rust free and clear of paint or grime.
REMOTE
Connect the REM terminal of the amplier to the power antenna terminal in the car ignition switch
using 12 or 14 ga. electrical wire.
Caution
This amplier is not supplied with a internal fuse.
Make sure you install a in-line fuse holder
from the postitive (+) terminal of battery.
Recommend 800 Ampere fuse.
POWER CONNECTIONS
BATTERY
GROUND
HEAD UNIT
FUSE
800A
