Crossfire XS-8K - DUAL AMP POWER CONNECTION (STRAPPED); POWER CONNECTION

Remote Turn-On
BATTERY
GROUND
GROUNDGROUND
GROUND
FUSE
800A
FUSE
800A
BATTERY
XS-8K Operating Voltage: 8.5V to 16V at 1Ohm.
XS-8X Operating Voltage: 8.5V to 18V at 1Ohm.
Strapped Minimum Impedance is 2 Ohms.
Caution !!
DUAL AMP POWER CONNECTION (STRAPPED)
POWER CONNECTION
