CROSSRC EMOX2 - Driveshaft and Gear Mesh; Gear Mesh Testing; Driveshaft Assembly

6
EMOX2
ESC
ON/OFF
Switch
Battery
(Not included)
ONOFF
Tips:
Test the gear mesh by connecting the ESC to the motor/gearbox
assembly. If the gearbox is not operating smoothly or is creating excess
noise, check the gear mesh prior to proceeding to the next step.
1
227802
227801
41297
41523
227803
41298
41524
11205
227803
41523
41298
41297
41524
227801
11205
THREAD
LOCK
THREAD
LOCK
7
EMOX2
11205
M3x6
BAG(BB)
x2
95094
17
