EMO X2 Assembly Remind
1. The spraying and bonding process to body shall be carried out in a ventilated place,and safety masks shall be worn.
2. Please conduct simulated assembly to determine the sequence of component before bonding or spraying.
3. For the wiring diagram of electronic equipment, please refer to the description on page 40 of the manual;
Please conduct power commissioning when the wheels are suspended.
4. This product is a high-precision model. Please read this manual carefully before assembly and assemble in strict
accordance with this manual.
5. Screw thread sealant shall be used during assembly. Please noted that the screw thread sealant shall not have any
contact with the shell parts. The screw thread sealant and ABS materials will produce chemical reaction, which will
embrittle and crack the shell.
6. It is recommended to use professional tools for installation. Please pay attention to the safety when use tools.
Requirements and recommendations for electronic equipment:
Name
Specifications Remarks
Remotes
controller
6 channels or Up
Waterproof connector is recommended
Servo
Shift servo ≥3KG x 3
Steering servo ≥25KG
High pressure standard Servo in waterproof
For the size of medium Servo, please refer
to the configuration drawing below
ESC
Continuous current ≥ 80A
ESC BEC >3A
Brush motor
Brushless motor
Brush motor 560 25T or Up
2200KV
The Max. Size: Ø39mm*80mm
Installation hole spacing: 25mm
Motor gear
M=0.8 Z=16T~20T
M=0.8 32P
Battery box size
Motor gear
Total reduction ratio
Environment
135*50*40 20T
Low speed 1:38.9
Suitable for crossing and climbing
High speed 1:17 8
Gear reduction ratio range reference
High speed
Low speed
2
20T19T
18T
17T
16T
1:22.1
1:48.3
1:45.4
1:20.8
1:19.6
1:42.9
1:18.6
1:40.6
1:17.8
1:38.9
