CE Series Service Manual
Rev. D
Exploded Views 6-29
Assy. CE 1000A Domestic (using PWA 102139-8) continued
Parts NOT shown in drawing on page 6-2:
Item Qty. Description CPN
1 Wire, 14 blk fast fast x 4.0 x flag A11384-C040M
1 Wire, 14 blk fast x 14 x tab A11384-C140N
1 Wire, 14 blk flag x 14 x flag A11384M140M
1 Wire, 14 grn #8ring x 5 x flag A12119-N050M
3 Tie, cable 4" or more 18 lb C 1811-6
X Threadlocker, Titan 7242 50 ML S 2217-8
8 Mscr, 6-32x.25 Torx Pn Hd Sem 103435-70604
1 Pnl, CD output blank 126730-1
1 Clip, D390 Breaker Mounting 125476-2
1 .25OD x .18ID x 1.062 AL SPCR A10100-50
1 8-32x3/8 pnhd T15 Thdrol sem b 126979-1
1 6-32x.31 pnhd acr ph tr isem b 127436-1
1 Serf PWA, CE1000 Main/input 02129-11
