Crown CH Series - Operation: Front Panel and Controls; Front Panel Overview; Back Panel Controls (CH1;CH2)

page 15
CH and CL Series Power Amplifiers
Operation Manual
3 Operation
Figure 3.1 CH and CL Series Front Panel Controls and Indicators
Figure 3.2 Models CH1 & CH2 Back Panel Controls and Connectors
(Shown with No-Touch Cover Removed)
SIGNAL SIGNAL
CLIP CLIP
FAULT FAULT
POWER
Power Switch
“OFF” Position “ON” Position
Power Indicator
Channel 1 Signal,
Clip & Fault Indicators
Channel 2 Signal,
Clip & Fault Indicators
