D. 7/8 dia. concealed conduit knock out mounting (in rear of housing) D. Pieza desmontable de 7/8" de diámetro (en la parte posterior de la carcasa) E. 0.201 dia. 2 holes (mounting) E. 2 orificios de montaje dia. 0,201 F. Collar nut F. Tuerca collar G. 0.201 dia 4 holes (mouting) G. 4 orificios de montaje dia. 0,201
Français D. Ejection diam. 7/8" (a l'arriere de l'enceinte) E. 2 trous de montage dia. 0,201 F. Ecrou collier G. 4 trous de montage dia. 0,201
-17-
1
290A2627-67B
MODEL
AM300
MODEL
AM300GCX
INCHES MM
A B C
206 320 209
8-1/8"
12-5/8"
8-1/4"
A" C"
B"
1-13/16"
(46.0mm)
2-9/16"
(65.1mm)
2-3/4"
(69.9mm)
1/2-14 NPT
5-5/8"
(142.88mm)
5-5/8"
(142.88mm)
13/16"
(20.64mm)
3-3/8"
(85.73mm)
13/16"
(20.64mm)
3-3/8"
(85.73mm)
5-1/2"
(139.7mm)
2-1/4"
(57.2mm)
3-1/4"
(82.6mm)
5"
(127mm)
B"
A" C"
1/2-14 NPT
F
G
F
D
E
