Operation Manual
MA 2402 Power Amplifier
page 22
8 Specifications
Performance (continued) Macro-Tech 2402
Load Impedance (Note: Safe with all types of loads)
Stereo
Bridge Mono
Parallel Mono
2-8 ohms
4-16 ohms
1-4 ohms
Voltage Gain (at maximum level setting, ± 6%)
0.775V sensitivity
1.4V sensitivity
26 dB gain
38 dB ± 0.5 dB
33 dB ± 0.5 dB
26 dB
Required AC Mains 50/60 Hz, 100-240VAC (+10%,–15%)
Power Draw at Idle 100 watts or less
Ventilation Flow-through ventilation from
front to side panels
Cooling Internal heat sinks with forced-air cooling for
rapid, uniform heat dissipation
Dimensions
Width
Height
Depth
EIA Standard 19-inch (48.3 cm) rack mount
(EIA RS-310-B)
3.5 inches (8.9 cm
16 inches (40.6 cm)
Weight
Net Weight
Shipping Weight
51 lb 12 oz (23.5 kg)
65 lb (29.5 kg)
