Networked PIP Series
page 18
Reference Manual
2. Connect the Audio Input Wiring. The PIP module is equipped with removable barrier block
connectors for each channel’s input. See Section 5.1 for more detail on audio wiring. The
USP3/CN allows the use of standard balanced audio inputs to act either as CobraNet
backup, an emergency override of CobraNet audio, or as an audio input to the CobraNet
network. See Section 5.1.6 for additional details. The single 5-pin removable barrier block
connector allows both audio channels to be inserted into the USP3/CN, then routed via
software control.
3. Connect the AUX wiring if used. See Section 7.1 for more information.
4. Reconnect the amplifier's power cord.
