138349-14 REV. A PWA, XTI4000 600029
R819 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX M 9
R820 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 B 10
R821 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 L 9
R822 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 A 10
R823 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 L 9
R824 A11368-49910 RES, 4.99 KOHM 1/16W 1% 0603 N 1
R825 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 H 2
R900 A11371-8205 82 OHM 1W 5% SMD 2512 A 3
R901 A11368-10041 1M OHM .1W 1% CHIP 0805 F 1
R902 A11368-10000 RES, 100 OHM 1/16W 1% 0603 F 1
R903 A11368-10000 RES, 100 OHM 1/16W 1% 0603 F 2
R904 A11368-49923 49.9KOHM .25W 1% CHIP 1210 P 8
R905 A11368-49923 49.9KOHM .25W 1% CHIP 1210 P 8
R906 A11371-8205 82 OHM 1W 5% SMD 2512 A 2
R907 A11371-8205 82 OHM 1W 5% SMD 2512 A 2
R908 A11371-8205 82 OHM 1W 5% SMD 2512 A 2
R918 A11368-33R20 RES, 33.2 OHM 1/16W 1% 0603 G 1
R919 A11368-33R20 RES, 33.2 OHM 1/16W 1% 0603 G 1
R920 A11368-10010 RES, 1.0 KOHM 1/16W 1% 0603 G 2
R925 A11368-33R20 RES, 33.2 OHM 1/16W 1% 0603 G 2
R926 A11368-33R20 RES, 33.2 OHM 1/16W 1% 0603 G 1
R927 A11368-33R20 RES, 33.2 OHM 1/16W 1% 0603 G 2
R928 A11368-33R20 RES, 33.2 OHM 1/16W 1% 0603 I 1
R929 A11368-33R20 RES, 33.2 OHM 1/16W 1% 0603 I 2
R931 A11368-33R20 RES, 33.2 OHM 1/16W 1% 0603 F 2
R938 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 G 1
R939 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 G 1
R990 A11368-47001 470 OHM, 0.10W 1% MF 0805 F 1
R993 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 F 2
R999 A11368-10031 100.KOHM .1W 1% CHIP 0805 I 12
RT1 OPEN D 7
RT2 OPEN D 4
RT3 138357-1 PRP, 101103-1 PTC .155 L 2
RT3X C 8982-8 TO-220 XSISTOR HOLDER, PLASTIC L 2
RT4 OPEN J 7
RT5 OPEN J 4
RT6 138357-1 PRP, 101103-1 PTC .155 P 3
RT6X C 8982-8 TO-220 XSISTOR HOLDER, PLASTIC P 3
S7 132498-1 SWITCH, DPST PUSHBUTTON VDECSA P 1
T1 138900-1 XFMR, E55 11:9:2 125KHZ O 6
TB1 OPEN F 12
TP1 OPEN H 1
TP2 127064-1 TEST POINT, SMT 1206 L 11
TP3 OPEN I 1
TP4 OPEN I 1
TP5 OPEN H 1
TP11 OPEN I 1
TP12 OPEN H 1
TP13 OPEN H 1
TP14 OPEN H 1
TP15 OPEN I 1
TP16 OPEN H 1
TP17 OPEN H 2
TP18 OPEN H 2
TP19 OPEN H 1
TP20 OPEN A 11
TP21 127064-1 TEST POINT, SMT 1206 P 5
TP22 127064-1 TEST POINT, SMT 1206 M 3
TP26 127064-1 TEST POINT, SMT 1206 M 9
XTi4000 BOM 138349-14_A.xls
R04.1CDE-004_(Fm) JAW 10/6/01
CROWN AUDIO, INC. ELKHART, IN. 29 OF 30
