139087-14 REV. A PWA, XTI1000 600029
R752 A11368-10R00 RES, 10 OHM 1/16W 1% 0603 I 11
R753 OPEN D 9
R754 OPEN D 9
R755 A11368-21510 RES, 2.15 KOHM 1/16W 1% 0603 M 3
R756 OPEN L 10
R757 OPEN L 10
R759 OPEN K 9
R760 OPEN K 9
R762 A11371-15R3 RES, 15 OHM .25W 5% 1210 T/R K 9
R763 A11371-15R3 RES, 15 OHM .25W 5% 1210 T/R K 8
R764 A11368-28701 287 OHM .1W 1% CHIP 0805 H 3
R765 A11368-28701 287 OHM .1W 1% CHIP 0805 H 3
R766 OPEN B 6
R767 A11368-12721 12.7K 0.1W 1% 0805 T/R C 5
R768 OPEN B 5
R769 A11368-12721 12.7K 0.1W 1% 0805 T/R C 3
R770 OPEN H 6
R771 A11368-12721 12.7K 0.1W 1% 0805 T/R I 5
R772 OPEN H 5
R773 A11368-12721 12.7K 0.1W 1% 0805 T/R I 3
R774 A11368-60420 RES, 60.4K OHM 1/16W 1% 0603 D 2
R775 A11368-60420 RES, 60.4K OHM 1/16W 1% 0603 K 2
R776 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX C 2
R777 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX E 3
R778 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX I 2
R779 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX K 3
R782 A11368-22R11 22.1 OHM 0.1W 1% 0805 T/R C 5
R783 A11368-22R11 22.1 OHM 0.1W 1% 0805 T/R C 3
R784 A11368-22R11 22.1 OHM 0.1W 1% 0805 T/R I 5
R785 A11368-22R11 22.1 OHM 0.1W 1% 0805 T/R I 3
R786 A11368-24910 RES, 2.49 KOHM 1/16W 1% 0603 C 2
R787 A11368-24910 RES, 2.49 KOHM 1/16W 1% 0603 L 2
R788 A11368-28003 280 OHM .25W 1% 1210 T/R C 8
R789 A11368-28003 280 OHM .25W 1% 1210 T/R B 8
R790 A11368-28003 280 OHM .25W 1% 1210 T/R L 8
R791 A11368-28003 280 OHM .25W 1% 1210 T/R K 8
R796 OPEN L 10
R797 OPEN K 9
R798 OPEN D 8
R799 OPEN B 8
R800 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX L 8
R801 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX J 8
R802 OPEN M 8
R803 OPEN J 8
R804 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX B 6
R805 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX C 5
R806 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX I 6
R807 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX I 5
R808 OPEN L 8
R809 A11368-49910 RES, 4.99 KOHM 1/16W 1% 0603 J 2
R810 A11368-10020 RES, 10.0 KOHM 1/16W 1% 0603 J 2
R811 A11368-49910 RES, 4.99 KOHM 1/16W 1% 0603 K 1
R812 A11368-10030 RES, 100.0 KOHM 1/16W 1% 0603 J 2
R813 A11368-24920 RES, 24.9 KOHM 1/16W 1% 0603 J 2
R814 A11368-40220 RES,40.2KOHM .0625W 1% 0603T/R J 2
R815 A11368-29421 29.4 KOHM .1W 1% 0805 T/R J 1
R816 A11368-20003 RES, 200 OHM 1% 0.25W 1210 T/R J 1
R817 A11368-20003 RES, 200 OHM 1% 0.25W 1210 T/R J 1
R818 OPEN C 9
XTi1000 BOM 139087-14_A.xls
R04.1CDE-004_(Fm) JAW 10/6/01
CROWN AUDIO, INC. ELKHART, IN. 28 OF 30
