19
WARNING
• The park brake will release automatically when either the accelerator or brake pedal is pressed. The park
brake has multiple locking positions and should be firmly pressed and locked to prevent the vehicle from
rolling.
NOTE: Vehicles equipped with lights: After the park brake is engaged, the brake lights will remain illuminated for up to
four minutes.
NEUTRAL LOCKOUT
For the convenience of the trained technician, there is a neutral lockout cam located on the back of the Forward/Reverse
shifter. If the neutral lockout cam is pulled out approximately 3/8 inch (10 mm) and then rotated one-half turn until it snaps
into place, the cam will be in the MAINTENANCE position (Figure 20). This will allow the technician to operate the engine in
neutral for certain maintenance procedures. With the cam in this position, the vehicle will not operate if the Forward/Reverse
handle is placed in either the FORWARD or REVERSE position.
To put the cam back into the OPERATE position, pull the cam out approximately 3/8 inch (10 mm) and rotate it one-half turn
until it snaps into place (Figure 21). See following WARNING and NOTE.
WARNING
• With the cam in the MAINTENANCE position and the engine running, the vehicle may move suddenly if the
Forward/Reverse handle is shifted or accidentally bumped. To prevent this, chock the front and rear wheels and
firmly set the park brake before servicing or leaving the vehicle.
NOTE: Be sure to return the cam to the OPERATE position after servicing the vehicle, or it will not operate with the
Forward/Reverse handle in either the FORWARD or REVERSE position.
