8.4 Channel description
Modbus
Register
Modbus
Address
No.of
Byte
Data Type
Description
Default
Setting
Read
Write
Comment
3001
3000
2
word
Channel A1
sensor type
0
R
Sensor Type *3)
3002
3001
24
string
Channel Name
0
R
Sensor Name *4)
3014
3013
2
word
name/unit index
value 1
0
R
Value description *5)
3015
3014
2
word
name/unit index
value 2
0
R
Value description *5)
3016
3015
2
word
name/unit index
value 3
0
R
Value description *5)
3017
3016
2
word
name/unit index
value 4
0
R
Value description *5)
3018
3017
2
word
name/unit index
value 5
0
R
Value description *5)
3019
3018
2
word
name/unit index
value 6
0
R
Value description *5)
3020
3019
2
word
name/unit index
value 7
0
R
Value description *5)
3021
3020
2
word
name/unit index
value 8
0
R
Value description *5)
3033
3032
2
word
Channel A2
sensor type
0
R
Sensor Type *3)
3034
3033
24
string
Channel Name
0
R
Sensor Name *4)
3046
3045
2
word
name/unit index
value 1
0
R
Value description *5)
3047
3046
2
word
name/unit index
value 2
0
R
Value description *5)
3048
3047
2
word
name/unit index
value 3
0
R
Value description *5)
3049
3048
2
word
name/unit index
value 4
0
R
Value description *5)
3050
3049
2
word
name/unit index
value 5
0
R
Value description *5)
3051
3050
2
word
name/unit index
value 6
0
R
Value description *5)
3052
3051
2
word
name/unit index
value 7
0
R
Value description *5)
3053
3052
2
word
name/unit index
value 8
0
R
Value description *5)
