8.8 Data Bit description
*1)
Data Value
Format (Dword / Float) depends on Value Description Bit 15
see below *5)
Position of Dezimal Point depends on Value Descrition Bit
14..12
see below *5)
*2)
Data Status
Write 1 to these bits
clears Status
Bit
15
Sensor changed
different sensor
Bit
14
Sensor setting changed
mayor parameter
changed
Bit
13
Sensor Alarm settings changed
Alarm settings changed
Bit
12
Sensor name changed
minor change
Bit
11
Lower Alarm active
Bit
10
Lower Warning active
Bit
9
Upper Alarm active
Bit
8
Upper Warning active
Bit
7
tbd
Value status
Bit
6
Channel Error
Value status
Bit
5
Value Error
Value status
Bit
4
out of range
Value status
Bit
3
Stopped
Value status
Bit
2
UVP status
Value status
Bit
1
OCP status
Value status
Bit
0
Channel Disconnected
Value status
*3)
Sensor Type
Bit
15..8
Sensor Basic type
0..255
0 = no sensor
Bit
7..0
Sensor Subtype
0..255
*4)
Channel Name
Name coding in UTF8 (max 24 Byte)
*5)
Value description
Bit
15
1 = Dword , 0 = float
0,1
Bit
14..12
position of dezimal point
0..7
Bit
11..7
index of value name
0..31
Bit
6..0
index of unit name
0..127
0 = value not used
