DS 400 Side 31 of 36
*6)
Alarm Channel / Value
Bit
11
lower Alarm used
Bit
10
lower Warning used
Bit
9
upper Alarm used
Bit
8
upper Warning used
Bit
7
Alarm used (valid)
Alarm settings used
Bit
6..4
Value Nr
0..7
Bit
3..0
Channel
0..11
*7)
Alarm Relais
Bit
15
Bit
14
Bit
13
Lower alarm Relais 2 used
Bit
12
Lower alarm Relais 1 used
Bit
11
Bit
10
Bit
9
Lower warning Relais 2 used
Bit
8
Lower warning Relais 1 used
Bit
7
Bit
6
Bit
5
Upper alarm Relais 2 used
Bit
4
Upper alarm Relais 1 used
Bit
3
Bit
2
Bit
1
Upper warning Relais 2 used
Bit
0
Upper warning Relais 1 used
