Valve Body Assembly - Signature 2
Ref #
Description Part # Qty.
1 Piston Assembly 20001X231 1
2 10-24 x 13/16 Screw 20001X226 3
3 Seal & Spacer Kit 20561X253 1
4 End Spacer N/S 1
5A Flow Control Button 5.0 GPM 20251X272 1
Flow Control Button 7.0 GPM 20251X274 1
6 Plastic Flow Control Housing 20017X100 1
6A Flow Control Assy. 5.0 GPM-PVC 20017X262 1
Flow Control Assy. 7.0 GPM-PVC 20017X264 1
7 Drain Line Fitting 1/2” NPT X 1/2” 20017X255 1
8 Drain Retainer 20017X214 1
9 Brine Valve 20561X225 1
10 BLFC Assembly .5 GPM 20001X228 1
11 Brine Line Ferrule 20251X305 1
12 Brine Line Compression Nut N/S 1
13 10-24 X 1 Hex Screw 20001X226 1
14 Injector Cap 20001X223 1
14a Injectory Kit-Specify Size- Inc. (1) ea
#14, #15, #16, #17 & (2) #13
20001X220 1
15 Injector Seal 20001X224 1
16 Injector Assy. Specify Size 20001X219 1
17 Injector Screen 20001X222 1
18 Injector Plug & O-Ring Assy. 20001X217 1
19 O-Ring 20561X205 1
20 O-Ring 20561X204 1
To Next Page
