Valve Body Assembly - Signature 3
Ref Description Part No. Qty
1 Piston Assembly 20001X231 1
2 10-24 X 13/16 Hex Head 20001X226 5
3 Seal and Spacer Kit 20561X253 1
4 Bottom Spacer N/S 1
5A Flow Control Button 5.0 GPM 20251X272 1
Flow Control Button 7.0 GPM 20251X274 1
6a Flow Control Assembly 1.5 20017X256 1
Flow Control Assembly 2.0 20017X257 1
6 Drain Line Flow Control Housing 20017X100 1
7 Drain Line Hose Barb, Straight 20017X255 1
8 DLFC Clip 20017X214 1
9 Brine Valve 20561X225 1
10 Brine Line Flow Control Assy. 20001X228 1
11 Brine Line Ferrule 20251X305 1
12 10-24 X 1 Hex Screw 20001X226 2
13 Injector Cover 20001X223 1
14 Injector Seal 20001X224 1
15 Injector w/ Check Ball 20001X219-1D 1
16 Injector Screen 20001X222 1
17 Injector Plug 20001X217 1
18 Tank O-Ring 20561X205 1
19 Distributor Pilot O-Ring 20561X204 1
20 Flow Meter 20017X203 1
21/22 Valve Complete VH1-B-D15 1
