17
Ref Description Part Number Qty
0 Powerhead Assy. 20015X100 1
1 Circuit Board Assy. 20015X101 1
2 Encoder 20001X124 1
3 Front Plate 20001X004 1
4 Encoder Wheel 20001X007 1
5 Main Gear 21001X120 1
6 Power Supply 20001X125 1
7 Back Plate 20001X005 1
8 Lower Front Base For Cover 20111X002 1
9 Microswitch 20251X113 1
10 Switch Spacer 20111X004 1
11 Brine Motor Mount 20111X006 1
12 Motor Assembly 20016X006 2
13 Brine Cam 20111X005 1
14 Lower Back Base For Cover 20111X003 1
15 Slide Cover 20111X000 1
16 Motor Screw SC2 4
17 Microswitch Screw SC3 2
18 Screw SC9 3
19 Screw SC10 3
20 Piston Screw 20001X003 1
21 Valve Hex Screw 20001X001 2
22 Circuit Board Washer 20111X014 1
23 Piston Washer 20001X002 1
Control Valve Powerhead Assembly
