DigiAir Pro 3
Technical Specifications
Dimensions
Radio: 75 mm (h) x 115mm (w) x 16mm (d)
LAN: 75mm (h) x 115mm (w) x 23mm (d)
Weight 106g excluding aerial
Temperature -10 °C to + 55 °C
Humidity 0 - 90% non-condensing
Mounting Via fixing points under main cover
Warranty 5 years
Power
Requirement
10 - 36 Volts.
In order to maintain compliance with requirements for electrical safety the
Dualcom Pro should always be powered from a fused supply with following
rating:
• For a 12V DC system (supply voltage in the range 10 Volts DC to 14 Volts
DC) a fuse rated at 1.25
• For a 24V DC system (supply voltage in the range 20 Volts DC to 36 Volts
DC) a fuse rated at 600 mA
If the power source is not limited to these values, then a fuse with the correct
rating must be fitted in line with the positive connection from the power
source.
The SPT will shut down on detecting a low supply of 7.6 Volts DC +/- 0.5 Volts
DC
Current
Consumption
DigiAir Pro 3 Radio attached to Security Panel: 66 mA (average value)
DigiAir Pro 3 Radio attached to Fire Panel: 55 mA (average value)
DigiAir Pro 3 LANattached to Security Panel: 78 mA (average value)
DigiAir Pro 3 LAN attached to Fire Panel: 62 mA (average value)
Radio Path 2G, 3G, 4G
Output Ratings
Maximum applied voltage = 60V
Maximum current = 150mA
Aerial 50 ohms (nominal) on MMCX socket
Operation Method Store and forward
CIE
Interconnections
Input triggering (standardised parallel), RS232, RS485, TTL
RCT Protocols SIA
Input Terminals
Max +30 Volts, Min 0 Volts DC (reference supply 0V) with a + or – 40%
change for > 200ms.
User Serviceable
Parts
There are no serviceable parts within the DualCom Pro Range
Applicable
Standards
Suitable for use in alarm systems complying to:
• EN50131-1:2006+A2:2017
• EN50136-1:2012+A1:2018
• PD6662:2017
• PD6669:2017
Emissions Standard – Radio Equipment Directive 2014/53/EU (RED) EN
50130-5 Environmental Class II
ATS Classification EN 50136-2:2013 SP2, SP3, SP4
ATS Configuration EN 50131-10:2014 Type Y
ATS Classification EN 50136-1-1:1998
• Radio D3, M3, T4, S2, I3, A4 (ATS5)
• LAN D3, M3, T4, S2, I3, A4 (ATS5)
