Verify the sticker position respectively to the central axis (A).
5
Remove the protection film. Place the sticker pad between
the two cogged wheels and the scrolling plate.
Respect the indicated distances while placing the sticker pad (for
right/left identification) on the table top.
Fig 13 – Distances
Fig 14 – Placement of the sticker pad
