sirius+ | IFU327EN00 - 01/2021
INSTRUCTIONS FOR USE
This document is the property of
CSO Costruzione Strumenti Oftalmici srl.
Any reproduction, even partial, it is prohibited.
35/56
Install the chin rest. Under the table top, there are two screws
to block the chin rest support to the table top.
The chin rest shall be installed so that the eye level
placed at a height of 380 mm from the table top.
Fig 18 - Placement of the chin rest Fig 19 – Correct height of the eye level indicator
