CANedge2 Docs, Release FW 01.04.02
Reception (rx) initial state properties.rx_state
The initial state of CAN-bus reception. Can be changed using the control signal.
type: integer default: 1 options: Disable: [0] Enable: [1]
Transmission (tx) initial state properties.tx_state
The initial state of CAN-bus transmissions. Can be changed using the control signal.
type: integer default: 1 options: Disable: [0] Enable: [1]
Configuration explained
This section contains additional information and examples.
0.4.5.2 Physical
This page documents the physical configuration
Configuration file fields
This section is autogenerated from the Rule Schema file.
Mode mode
Device CAN bus mode. Configures how the device interacts with the bus. In Normal mode, the device can
receive, acknowledge and transmit frames. In Restricted mode, the device can receive and acknowledge,
but not transmit frames. In Bus Monitoring mode, the device can receive, but not acknowledge or transmit
frames. It is recommended to always use the most restrictive mode possible.
type:
integer
de-
fault:
1
options: Normal (receive, acknowledge and transmit): [0] Restricted
(receive and acknowledge): [1] Monitoring (receive only): [2]
Automatic retransmission retransmission
Retransmission of frames that have lost arbitration or that have been disturbed by errors during trans-
mission.
type: integer default: 1 options: Disable: [0] Enable: [1]
CAN FD specification fd_spec
Configures the CAN FD specification used by the device. Shall match the specification used by the CAN
bus network.
type:
integer
default:
0
options: ‘‘ ISO CAN FD (11898-1): [0]‘‘ non-ISO CAN FD (Bosch V1.0.
): [1]
