Example: Data prescaling applied to ID 800
10
with mask 1 (considering only changes to the 1st data
byte). D0-D3 is a 4-byte payload (with D0 the first data byte).
ID (DEC) D0 D1 D2 D3 Result
800
10
00 11 22 33 Accept
800
10
00 11 22 33 Reject
800
10
00 BB 22 33 Reject
800
10
AA BB 22 33 Accept
800
10
AA BB 22 DD Reject
800
10
AA BB 22 DD Reject
Example: Data prescaling applied to ID 800
10
with mask 8 (considering only changes to the 4th data
byte). D0-D3 is a 4-byte payload (with D0 the first data byte).
ID (DEC) D0 D1 D2 D3 Result
800
10
00 11 22 33 Accept
800
10
00 11 22 33 Reject
800
10
00 BB 22 33 Reject
800
10
AA BB 22 33 Reject
800
10
AA BB 22 DD Accept
800
10
AA BB 22 DD Reject
Example: Data prescaling applied to ID 800
10
with mask 9 (considering only changes to the 1st or 4th
data byte). D0-D3 is a 4-byte payload (with D0 the first data byte).
ID (DEC) D0 D1 D2 D3 Result
800
10
00 11 22 33 Accept
800
10
00 11 22 33 Reject
800
10
00 BB 22 33 Reject
800
10
AA BB 22 33 Accept
800
10
AA BB 22 DD Accept
800
10
AA BB 22 DD Reject
0.4.5.4 Transmit
This page documents the transmit configuration.
Configuration file fields
This section is autogenerated from the Rule Schema file.
Transmit messages ‘‘ ‘‘
List of CAN bus messages transmitted by the device. Requires a CAN-bus physical mode supporting
transmissions.
type: array maxItems: 64
Name items.properties.name
Optional transmit message name.
