CANedge2 Docs, Release FW 01.04.02
type: string maxLength: 16
State items.properties.state
Disabled transmit messages are ignored.
type: integer default: 1 options: Disable: [0] Enable: [1]
ID Format items.properties.id_format
ID format of the transmit message.
type:
integer
de-
fault:
0
oneOf: [{'type': 'integer', 'title': 'Standard (11-bit)', 'enum':
[0]}, {'type': 'integer', 'title': 'Extended (29-bit)', 'enum':
[1]}]
Frame format items.properties.frame_format
Frame format of the transmit message.
type: integer default: 0 options: Standard: [0] Standard RTR: [2] FD: [1]
Bit-Rate Switch items.properties.brs
Determines if an FD message is transmitted using a switched bit-rate.
type: integer default: 0
Include in log items.properties.log
Determines if the transmitted message is included in the log file.
type: integer default: 0 options: Disable: [0] Enable: [1]
Period (10 ms steps) items.properties.period
Time period of the message transmission. 0: single shot, >0: periodic. Unit is ms.
type: integer minimum: 0 maximum: 4294967290 multipleOf: 10
Delay (10 ms steps) items.properties.delay
Offset message within the period or delay a single shot message. If multiple messages are transmitted by
the device, it is recommended to offset each separately to reduce peak load on bus. If period > 0, delay <
period. If single-shot, delay can be up to max value. Unit is ms.
type: integer minimum: 0 maximum: 4294967290 multipleOf: 10
0.4. Configuration 33
