CANedge2 Docs, Release FW 01.04.02
Mode mode
Device LIN bus mode.
type: integer default: 0 options: Subscriber: [0] Publisher: [1]
Bit-rate bit_rate
type:
integer
default:
19200
options: 2400: [2400] 9600: [9600] 10400: [10400] 19200:
[19200]
Configuration explained
This section contains additional information and examples.
0.4.6.2 Frame Table
This page documents the frame table configuration
Configuration file fields
This section is autogenerated from the Rule Schema file.
Name name
Optional frame name.
type: string maxLength: 16
Frame ID (hex) id
ID of frame in hex. Example: 0F.
type: string maxLength: 2
Frame Length (decimal) length
Length of the frame in decimal.
type: integer minimum: 1 maximum: 8
Checksum Type checksum_type
Type of the checksum used on the LIN frame.
type: integer default: 0 options: Enhanced: [0] Classic: [1]
0.4. Configuration 41
