Configuration explained
This section contains additional information and examples.
The LIN controller expects default data lengths and checksums as explained in LIN . LIN-frames using
a different configuration (length, checksum or both) can be explicitly configured using the frame table.
Note: LIN frames satisfying the default expected configuration do not need to be inserted in the frame
table
0.4.6.3 Transmit
This page documents the transmit configuration
Configuration file fields
This section is autogenerated from the Rule Schema file.
Name name
Optional transmit rule name.
type: string maxLength: 16
State state
Disabled transmit rules are ignored.
type: integer default: 1 options: Disable: [0] Enable: [1]
Frame ID (hex) id
type: string maxLength: 2
Data (hex) data
type: string maxLength: 16
Configuration explained
This section contains additional information and examples.
The interpretation of the transmit list depends on the configuration of LIN bus mode:
Publisher mode
The number of bytes entered in the data field determines the interpretation of the transmission frame:
