XP5 • 9
TECHNICAL DATA
ACCURACY: Up to 3/16-in @100-ft (± 4.8mm @ 30m)
Down Plumb: Up to 1/4-in @ 10-ft (± 6 mm at 3 m)
VISIBILITY RANGE: up to 100-ft (30 m) according to the light conditions
SELF-LEVELING RANGE: ± 5° in any direction
INDICATING LIGHTS: Low power: LED blinks Green
Out of level: LED Solid Red
POWER: 3 “AA” batteries 1.5 V
LASER OUTPUT: Class 3R or Class 2M, 5 laser diodes, 630–670 nm.
0.8-1.0 mW each for class 2M;
0.8-2.5 mW for class 3R, each
WEIGHT: 1.2lb (545g) with batteries
OPERATING TEMPERATURE: 32°-104°F (0°-40°C)
TRIPOD MOUNTING: 1/4-20
ENVIRONMENT: IP 54 Dust and Water Protection
MAINTENANCE AND CARE
The XP5 is not waterproof. Do not allow the unit to get wet. Damage to internal circuits will result.
Do not leave the XP5 out in direct sunlight or expose it to high temperatures. The housing and
some internal parts are made of plastic and may become deformed at high temperatures.
Do not store the XP5 in a cold environment. Moisture will form on interior parts when warming up.
The moisture could fog up laser windows and cause corrosion of internal circuit boards.
When working in dusty locations, some dirt will collect on the laser window. Remove any moisture
or dirt with a soft, dry cloth.
Do not use aggressive cleaning agents or solvents.
Store the XP5 in its case when not in use. Remove batteries before storage of the instrument.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing as waste. The machine, accessories and
packaging should be sorted for environmental-friendly recycling.
Do not throw used batteries into house waste, fire, or water, but dispose of in an environmentally
friendly manner according to the applicable legal regulations.
