CTC Union 950 - 12 Chimney Solutions; Balanced Flue System 80;125

30
12. CHIMNEY SOLUTIONS
1(2)
161 365 05 02-01
12.1 Balanced flue system 80/125 The installation must be performed according to the local regulations.
We reccomend to use the chimney solution according to figure A if
possible.
Max 7 meter
(including horisontal length)
A
ÇÇ
ÇÇ
Ç
ÈÈ
ÈÈ
È
B
ÅÅ
ÅÅ
Å
ÆÆ
ÆÆ
Æ
Max 3 meter
