01. TECHNICAL DATA
1(10)
161 145 07 02-01
1.1 General description The CTC 950 is a wall mounted oil fired unit. CTC 950 is delivered with
expansion vessel, circulation pump, oil burner, instrument panel and
safety valve.
CTC 950 combines small dimensions, easy maintenance, extremely low
noise level and high efficiency.
CTC Quality : Made in Sweden:The main task of the CTC engineers has always been
and will be to combine Swedish steel quality and innovative techniques of
thermic exchange in order to ensure highest efficiency and long life and
at the same time respecting nature and environment
Modern design: The new compact design of the oil wall-mounted unit - CTC 950 -is a
new innovative development which satisfies the needs of present and
future markets in every aspect. The simple and attractive casing
conceals a complete central heating system.
Compact air/flue-gas system : The new CTC 950 wall-mounted boiler unit can be used as preferred for
operation that is dependent on or independent of the room air.
The CTC LAS system is made of high-grade INOX stainless steel and
can be used with advantage for the concentric connection of the air
supply and flue gas duct in houses without a conventional chimney.
The supply air connection can also be made using a separate connecting
piece.
If the house already has a chimney, this can continue to be used with the
CTC LAS system. The CTC 950 wall-mounted boiler unit is available in
several models. It can be equipped at the factory with the preferred
burners.
1.2 Technical data CTC 950
Output kW 23,3
Input kW 25,5
Weight kg 112
Boiler efficiency % 91,5
Water content l 23
Flue gas outlet ø 82 mm int.
Air inlet ø 80 mm
Heating flow G 3/4”
Heating return G 3/4”
Expansion vessel l 10
Max working pressure bar 3
Test pressure (in production) bar 4,3
Safety valve bar 2,5
Boiler water resistance T 20° 20 mbar
Option: Heat exchanger
Hot water capacity 10-45°C l/min 9,3
Option: Hot water tank
Hot water capacity 10-45°C l/h 620
l /10 min 250
<
