Trouble Shooting Guide 13
Explanation 5: The charge cycle is interrupted in step 2.
Test: Test to restart the charge cycle with the mode button, if it still fails in step
2 the battery is can’t be charged and needs to be replaced.
Explanation 6: The charge cycle is interrupted in step 5.
Explanation 6.1: Large loads are connected to the battery and drain the
voltage.
Test: Disconnect the loads and try charging again.
Explanation 6.2: The battery cannot retain the charge provided.
• Temperature LED is lit
Explanation: This led is turned on automatically when the temp sensor is
connected.
• Temperature LED is not lit
Explanation: The temperature sensor is disconnected or has been damaged.
The charger will assume room temperature and charge without temperature
compensation.
• Temperature LED is flashing
Explanation: The temperature is above + 65 °C. The current is reduced until
the temperature has dropped below + 65 °C. The charger reverts to normal
charging current when the temperature drops below + 65 °C.
