4 • EN
MODE
START
STOP
STOP
SUPPLY
BOOST
Ca/Ca
AGM
NORMAL
SET
1 2 3 4 5 6 7 8
12V/40A
24V/20A
MXTS 40
CORD SET PRO
CORD SET PRO
female connector +
Temperature sensor
male connector
CORD SET PRO
female connector -
Charger cable
male connector +/-
Mains cable
Clamps
Eyelets M6
Temperature sensor
Mains cable connector/
Mains switch
Temperature sensor
female connector
USB Type B contact
