12 • EN
LITHIUM*
CHARGING PROGRAMS
Settings are made by pressing the MODE-button. After about
two seconds the charger activates the selected program. The
selected program will be restarted next time the charger is
connected.
The table explains the different Charging
Programs:
Program Explanation
LITHIUM
Lithium* battery program 14.2V/2.3A
Use for LITHIUM* batteries.
BATTERIES WITH "UNDER
VOLTAGE PROTECTION"
Some Lithium* batteries have an on-board UVP (under voltage
protection) that disconnects the battery to avoid it becoming
too deeply discharged. This prohibits the charger from
detecting that there’s a battery connected. To bypass this, the
battery charger needs to open the UVP. There are two options
available to “wake up” the battery - automatic and manual.
During the automatic “wake up” period the LED "CHECK" will
flash until the charge program is started and LED "CHECK" is
lit with a steady light. Automatic "wake up" will be active for
maximum 5 minutes.
If the charger is in Standby mode after 10 minutes ( power
led is flashing) the automatic wake up did not succeed. Try the
manual wake up.
To use the manual “wake up”, press the Mode button for
approximately 10 seconds to bypass the UVP. During the
“wake up” period the LED "CHECK" will flash until the charge
program is started and the LED "CHECK" is lit with a steady
light. If the manual wake up is unsuccessful the power LED
will start to flash after latest 10 minutes. Disconnect any
parallel loads from the battery and try again. If the charging
does not start after that, the battery may need to be replaced.
*) 12V lithium batteries (LiFePO
4
, Li-Fe, Li-iron, LFP)
