CTEK POWERSPORT User Manual

14 • EN
TECHNICAL
SPECIFICATIONS
Model number 1090
Input 110–120VAC, 50–60Hz, 1.1A
Output 12V/2.3A
Back current drain* Less than 1.5Ah/month
Ambient temperature -4°F to +122°F (-20˚C to +50˚C)
Battery types
12V: WET, EFB, MF, Ca/Ca, AGM,
GEL, LiFePO
4
Battery capacity 5–25Ah
CEC-400
Battery capacity
25Ah
Warranty 5 Year
Temperature
Compensation
Built in charge voltage
compensation according to ambient
temperature.
*) Back current drain is the current that drains the battery if
the charger is not connected to the mains. CTEK chargers has
a very low back current.
MAINTENANCE
INSTRUCTIONS
Powersport (1090) is maintenance-free. The charger must not
be opened; doing so will invalidate the warranty. If the mains
cable is damaged the charger must be returned to the retailer.
The charger casing can be cleaned using a damp cloth and
mild cleaning agent. Remove the plug from the power socket
before cleaning.

CTEK POWERSPORT Specifications

General

Input Voltage	220–240VAC, 50–60Hz
Charging Current	0.8A
Back Current Drain	<1Ah/month
Ambient Temperature	-20°C to +50°C
Start Voltage	2.0V
Ripple	<4%
Protection Class	IP65
Battery Types	12V: Wet, MF, Ca/Ca, AGM, GEL
Dimensions	168 x 65 x 38 mm
Protection Features	Reverse polarity protection, Short circuit proof
Output Voltage	12V
Charging Modes	8-step charging program
