Figure 14
Engine
Refer to the separate engine manual for engine
maintenance instructions.
Service air cleaner every 25 hours under normal
conditions. Clean every few hours under extremely
dusty conditions. To service the air cleaner, refer to the
separate engine manual.
The spark plug(s) should be cleaned and the gap reset
once a season. Spark plug replacement is recom-
mended at the start of each mowing season. Check
engine manual for correct plug type and gap
specifications.
Fuel Tank
The fuel tank cap is located on the left rear fender
panel. Remove the fuel cap by unscrewing and fill the
gas tank from this point.
Control Tower
Grease Fittings
Caster Wheel
Grease Fitting
Pivot Bar
Grease Fitting
Caster Wheel
Spindle Grease
Fitting
Deck Lift Pivot
Grease Fittings
Lift Handle
Grease Fitting
54” Mower Deck Grease Fittings
44” Mower Deck Grease Fittings
