35
Model 365
REF.
NO.
PART
NO. DESCRIPTION
1. 751-3141 Oil Drain Hose
2. 751-3142 Oil Drain Cap
3. 751-3140 Oil Drain
4. 710-3009 Screw #10-24 x .750
5. 746-3070 Throttle Control Cable 40.5”
6. 746-3066 Choke Control Cable 38.0”
7. 710-3008 Hex Cap Screw 5/16-18 x .75
8. 726-3008 Cable Clip Heat Shield
9. 712-3004A Hex Lock Nut 5/16-18
10. 749-3048 Fuel Line
11. 726-0205 Hose Clamp
12. 725-1711 Retainer Clip
13. 712-0161 Lock Nut #10-24
14. 736-0607 Lock Washer 5/16
15. 751-0535 Fuel Line Hose
16. 712-0431 Flange Lock Nut 3/8-16
17. 736-0258 Flat Washer .385 ID x 1.0 OD
18. 747-3362 Rear Belt Retainer Rod
19. 751-0644A Exhaust Pipe LH
20. 710-3178 Carriage Bolt 3/8-16 x .75
21. 751-0645 Exhaust Pipe RH
22. 710-0642 Hex Washer Screw 1/4-20 x .75
23. 736-3010 Flat Washer .407 ID x .812 OD
24. 703-2859 Muffler Bracket
25. 603-0317 Clutch Retainer Ass’y
26. 710-1007 Hex Washer Screw 3/8-16 x 1.5
27. 710-1008 Hex Washer Screw 3/8-16 x 1.875
28. 754-3100 V-Belt
29. 736-0250 Flat Washer 1.0 ID x 1.75 OD
30. 756-3060A Drive Pulley
31. 703-3004 Muffler Bracket
32. 714-0128 Key
33. 751-0805 Duel Muffler
34. 725-0157 Cable Tie
35. 717-3389 Electric PTO Clutch
36. 751-0564 Muffler Deflector
37. 750-3106 Spacer Clutch
38. 736-0171 Lock Washer 7/16
39. 710-3157 Hex Cap Screw 7/16-20 x 3.25
40. 710-0148 Hex Washer Screw #8-32 x .375
629-3035 Engine Harness Assembly (Not Shown)
REF.
NO.
PART
NO. DESCRIPTION
To Next Page
