51
Model 364
REF.
NO.
PART
NO. DESCRIPTION
1. 732-0556 Extension Spring .94 OD x 7.57
2. 712-3006 Hex Nut 1/4-20
3. 710-0597 Hex Cap Screw 1/4-20 x 1.0
4. 710-3151 Hex Cap Screw 5/8-18 x 4.25
5. 736-0290 Flat Washer 5/8 ID x 1.0 OD
6. 741-0524 Bearing .625 ID x 1.574 OD
7. 754-3091 Belt
8. 716-3020 Snap Ring
9. 750-3164 Spacer .635 ID x 2.0
10. 712-0239 Hex Lock Nut 1/2-20
11. 736-0179 Flat Washer 1/2 x 1.25
12. 736-0188 Flat Washer .76 ID x 1.49 OD
13. 741-0338 Flange Bearing 3/4 ID x .52
14. 750-0656 Spacer .50 OD x .75 ID
15. 756-3108 Pulley
16. 732-0850 Extension Spring 1.0 OD x 6.140
17. 603-0743 Idler Assembly
18. 736-0100 Flat Washer .531 ID x 1.25 OD
19. 737-3000 Grease Fitting
20. 738-3172 Shoulder Screw
21. 603-0741 Idler Arm Assembly
22. 732-3067 Torsion Spring
23. 756-3005 Flat Pulley
24. 712-0431 Flange Lock Nut 3/8-16
25. 748-3100 Retainer Spring
26. 603-0763 Deck Mounting Plate Assembly
27. 712-3004A Flange Lock Nut 5/16-18
28. 703-2559 Stop Bracket
29. 710-3008 Hex Cap Screw 5/16-18 x .75
30. 726-3045 Button Plug
31. 703-3742 Belt Cover LH
32. 712-3010 Hex Nut 5/16-18
33. 736-0119 Lock Washer 5/16
34. 738-0213 Shoulder Screw .498 x 1.445
35. 736-0192 Flat Washer .531 x .93
36. 603-0766 Handle Assembly
37. 710-1693 Spindle Bolt 3/4-16 x 5.215
38. 756-3089 Pulley
39. 710-3144 Hex Cap Screw 3/8-16 x 2.0
41. 710-1611A Screw 5/16-18 x .750
42. 748-3065 Spindle Spacer
43. 715-3003 Pin
44. 747-3013 Support Pin
45. 732-0802 Compression Spring .63 OD x 6.3
46. 710-1260A Hex Washer Screw 5/16-18 x .750
47. 750-3119 Spacer .406 ID x 1.0 OD
48. 750-0150 Spacer .550 ID x .750 OD
49. 603-0734 Deck Assembly
50. 710-3178 Carriage Bolt 3/8-16 x .75
51. 754-3039 Belt
52. 618-3129 Spindle Assembly
53. 748-3020 Blade Spacer
54. 742-3036 Blade
55. 712-3078 Hex Flange Nut 3/4-16
56. 736-0171 Lock Washer 7/16
57. 712-3019 Hex Nut 7/16-14
58. 736-0105 Bell Washer .401 ID x .870 OD
59. 703-1890 Deck Wheel
60. 631-0094 Chute Assembly
61. 738-3056 Shoulder Screw 1/2 x 2.5
62. 703-3359 Skirt Baffle
63. 710-0260A Carriage Bolt 5/16-18 x .62
64. 731-3316 Mulching Plug
65. 711-3314 Roller Pin
66. 703-3743 Belt Cover RH
67. 731-3005 Front Roller
68. 714-0115 Pin
69. 736-0270 Bell Washer .265 ID x .75 OD
70. 710-0751 Hex Cap Screw 1/4-20 x .620
REF.
NO.
PART
NO. DESCRIPTION
IMPORTANT: For a proper working machine, use Factory Approved Parts.
V-Belts are specially designed to engage and disengage safely. A substitute (non OEM) V-belt can be dangerous
by not disengaging completely.
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Cub Yellow, the part number to
order would be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Cub Blue: 0685
Powder Black: 0637
