53
Model 365 & 365L
REF.
NO.
PART
NO. DESCRIPTION
1. 720-0241 Wing Nut Knob
2. 703-2817 Belt Cover LH
3. 703-2816 Belt Cover RH
4. 747-3306 Idler Spring Mounting Rod
5. 738-0380 Shoulder Screw 3/8-16
6. 756-3106 Pulley
7. 712-0431 Flange Lock Nut 3/8-16
8. 710-0521 Hex Cap Screw 3/8-16 x 3.0
9. 736-0258 Flat Washer .385 ID x 1.0 OD
10. 756-3105 Idler Pulley 5.0
11. 603-0690 Deck Spindle Ass’y
12. 603-0469A Idler Bearing Arm Ass’y
13. 711-0242 Spacer
14. 738-3108 Shoulder Bolt
15. 737-0280 Grease Fitting
16. 736-3015 Flat Washer .469 ID x .875 OD
17. 603-0407 Idler Pulley Ass’y 5.0
18. 736-0316 Flat Washer .78 ID x 1.59 OD
19. 703-2849 Channel
20. 703-0326 Front End Deck Bracket LH
21. 703-2091A Front Roller Bracket
22. 714-0115 Cotter Pin
23. 711-3314 Roller Pin
24. 731-3005 Roller
25. 703-2430 Front End Deck Bracket RH
26. 703-2090 Reinforcement Disk RH
27. 703-2767 Front End Deck Bracket LH
28. 703-2089A Reinforcement Disk
29. 732-0971 Extension Spring
30. 712-0375 Lock Nut 3/8-16
31. 710-3168 Carriage Bolt 3/8-16
32. 603-0325 Mower Deck Ass’y
33. 747-3297A Deck Support Rod
34. 732-0395 Extension Spring .50 OD x 2.51 Lg
35. 711-1103 Pin Roller
36. 703-2929 Deck Support Link
37. 736-0231 Flat Washer .344 ID x 1.125 OD
38. 712-3004A Flange Lock Nut 5/16-18
39. 710-3168 Carriage Bolt 3/8-16
40. 731-3005 Roller
41. 738-0296 Shoulder Screw
42. 750-3243 Spacer
43. 703-3381 Idler Support Plate
44. 710-0944 Hex Cap Screw 3/8-16 x 4.25
45. 736-0227 Flat Washer
46. 736-0171 Lock Washer 7/16
47. 712-3019 Hex Nut 7/16-14
48. 703-2988 Support Plate
49. 710-3034 Carriage Screw 3/8-16 x 1.25
50. 603-0144 Front Bar
51. 750-3119 Spacer
52. 703-2099 Finger Guard
53. 703-2392 Bracket
54. 732-3070 Torsion Spring
55. 725-0157 Cable Tie
56. 710-3001 Hex Cap Screw 3/8-16 x .880
57. 703-2410 Castor Bracket
58. 634-3159 Wheel Complete
59. 750-3193 Spacer
60. 711-3318 Hinge Pin
61. 731-3131 Deflector Chute
62. 703-2093 Inner Baffle
63. 710-3178 Carriage Bolt 3/8 - 16
64. 742-3013 Blade
65. 754-3078 Belt
754-3083 Belt
66. 747-3013 Support Pin
67. 732-0802 Compression Spring
68. 736-0160 Flat Washer .536 ID x .93 OD
69. 715-3003 Spring Pin
70. 603-0351 Rear Hanger Bracket LH
603-0350 Rear Hanger Bracket RH
71. 703-2683 Rear Hanger Bracket Spacer
72. 710-0693 Hex Cap Screw 3/8-16 x 4.5
REF.
NO.
PART
NO. DESCRIPTION
IMPORTANT: For a proper working machine, use Factory Approved Parts.
V-Belts are specially designed to engage and disengage safely. A substitute (non OEM) V-belt can be dangerous
by not disengaging completely.
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Cub Yellow, the part number to
order would be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Cub Blue: 0685
Powder Black: 0637
