-27-
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
629-3062 Harness, Engine Wire ............... 1
1 603-0744 0637 Bracket, Engine LH ................... 1
2 603-0745 0637 Bracket, Engine RH ................... 1
3 651-0007
759-04009
Filter Assembly, Fuel .................
Filter Element .........................
1
1
4 703-3483
777S30631
777S30633
Plate, Radiator Baffle ................
Graphic, Fan Warning ............
Graphic, Warning ...................
1
1
1
5 703-3484
777S30632
Bracket, Radiator Mtg. RH ........
Graphic, Warning ...................
1
1
6 703-3485
777S30632
Bracket, Radiator Mtg. LH .........
Graphic, Warning ...................
1
1
7 703-05135 Bracket, Air Cleaner Mtg. .......... 1
8 703-3603A Bracket, Fuel Filter Mtg. ............ 1
9 703-05140 Plate, Baffle LH ......................... 1
10 703-05141 Plate, Baffle, RH ........................ 1
11 703-3741 Bracket, Radiator Mtg. .............. 1
12 710-0224 Screw, Hex Wash Hd Tapp .......
10-16 x .5
1
13 710-0347 Screw, Hex Cap ........................
3/8-16 x 1.75 GR5
2
14 710-0597 Screw, Hex Cap ........................
1/4-20 x 1.0 GR5
2
15 710-0599 Screw, Hex Wash Hd Tapp .......
1/4-20 x .5
1
16 710-0607 Screw, Hex Wash Hd Tapp .......
5/16-18 x .5
6
17 710-0623 Screw, Hex Wash Hd Tapp .......
3/8-16 x .75
4
18 710-1260A Screw, Hex Wash Hd Tapp .......
5/16-18 x .75
10
19 710-1376 Screw, Hex Cap, M8-1.25 x 16 2
20 710-1681 Screw, Hex Cap, M8-1.25 x 20 5
21 710-3005 Screw, Hex Cap, .......................
3/8-16 x 1/25 GR5
2
22 710-3008 Screw, Hex Cap ........................
5/16-18 x .75 GR5
9
23 710-3015 Screw, Hex Cap ........................
1/4-20 x .75 GR5
7
24 710-3138 Screw, Hex Cap,l M8-1.25 x 16 16
25 710-3144 Screw, Hex Cap ........................
3/8-16 x 2/0 GR5
4
26 712-0324 Nut, Hex Insert Lock, 1/4-20 ...... 9
27 712-0431 Nut, Hex Flange Lock, 3/8-16 .... 8
28 712-3004A Nut, Hex Flange Lock, 5/16-18 .. 9
29 717-3524 Shaft, Drive ................................ 1
30 720-0425 Plug, Cap ................................... 1
31 722-0262 Mount, Neoprene Engine .......... 4
32 722-3022 Tape, Foam, .625 wide .............. 42in.
33 723-3061 Seal, Heat Baffle ....................... 96in.
34 725-3281 Wire, Battery Pos. ..................... 1
35 725-3283 Wire, Ground ............................. 1
36 725-3287 Wire, Battery Neg. ..................... 1
37 726-0205 Clamp, Hose .............................. 7
38 726-0476 Clamp, Adjustable Hose ............ 3
39 726-0480 Clamp, Hose .............................. 2
40 731-04018 Grommet, Hose Guard .............. 2
41 731-04269 Hose, Radiator to Engine .......... 1
42 731-04232 Hose, Air Filter ........................... 1
43 731-04210 Hose, Air Inlet ............................ 1
44 731-3350 Hose, Engine to Radiator .......... 1
45 731-04193 Shroud, Fan ............................... 1
46 735-0226 Grommet, Rubber ...................... 1
47 736-0148 Washer, External Lock, 3/8 ....... 1
48 736-0173 Washer, Flat, .28 x .74 x .063 ... 7
49 736-0607 Washer, External Lock, 5/16 ..... 2
50 751-0535 Hose, Fuel Line ......................... 92in.
51 751-0822 Fitting, 90 Degree Hose ............ 1
52 751-0823 Fitting, Straight Hose ................. 1
53 751-3001 Plug, Drain ................................. 2
54 751-3130 Fuel Line, 5/16 ID ...................... 92in.
55 651-04010 Muffler, Engine .......................... 1
56 751-3165
722-0268
Radiator .....................................
Grommet, Rubber Mtg. ..........
1
2
57 751-3192 Cap, Radiator, 13psi .................. 1
58 751-3193 Screen, Debris ........................... 1
59 718-3132 Cooler, Oil ................................. 1
60 751-3194 Element, Air Cleaner ................. 1
61 751-3195 Cap, Air Cleaner ........................ 1
62 731-04228 Cannister, Air Cleaner ............... 1
63 751-3197 Nozzle, Air Cleaner ................... 1
64 BS-825462 Bottle, Overflow ......................... 1
65 710-3206A Screw, Hx Cap, M8-1.25:25 GR8 1
66 726-0132 Clamp, Hose .............................. 2
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
ENGINE AND DRIVE SHAFT
† Not Shown
