Cub Cadet 7304 - Crankcase Cover

-34-
CRANKCASE COVER
1
2
3
4
5
6
7
8
2
3
4
4
7
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 BS-821071 Seal, Oil ........................................... 1
2 BS-820425 Screw, Hex, 6mm ............................ 2
3 BS-820029 Screw, Hex, 6mm ............................ 9
4 BS-820027 Screw, Hex, 6mm ............................ 3
5 BS-825610 Cover Assembly, Gear ..................... 1
6 BS-820377 Gasket, Gear Cover ......................... 1
7 BS-820069 Nut, Hex Metric ................................ 2
8 BS-820061 Pin, Locating .................................... 2
9 BS-821077 Cap, Oil Fill ...................................... 1
9
