Chassis
5‐41
Rear Bridge
No. Part Name Qty Remarks
1
Circlip 2
2
Boot band 2
3
Boot band 2
4
Dust boot 2
5
Circlip 1
6
Double off-set joint assembly 1
7
Circlip 1
8
Circlip 1
9
Double off-set joint assembly 1
10
Joint shaft 1
11
Half axle assembly 1
